Kub OEM Industrial Water Chiller with 3HP to 50HP Semi Hermetic Compressor and 380V 50Hz Power Supply with 1 Year Warranty

Place of Origin : China

Brand Name : KUB

MOQ : 2

Price : $1,000

Voltage : 380V 50Hz

Power : 2.5 kW

Weight : 600 KG

Refrigerant : R-404a

Working temperature : 7 degree

Cooling capacity : 9.3 kW to 186 kW

Compressor power : 2.2 kW to 9.0*5 kW

Condenser type : Shell and tube

Water pump power : 0.37 kW to 3.75 kW

Pump pressure : 0.18 Mpa

Evaporator type : Coil /Shell and tube

Chilled water flow : 1.8 m³/hr to 33 m³/hr

Cooling water flow : 2.16 m³/hr to 37.8 m³/hr

Pipe diameter : 3/4" to 3"

Dimensions : 900x560x900 mm to 2300x750x1700 mm

Contact Now

Product Description

kub OEM water cooled water chiller semi hermetic compressor industrial chiller and 3HP to 50HP water chiller

	Model of Machine	3HP	4HP	5HP	6HP	8HP	10HP	12HP	15HP
Cooling capacity	kw	9.3	12.4	15.5	18.6	24.8	31	37.2	46.5
Cooling capacity	Kcal/hr	7998	10664	13330	15996	21328	26660	31992	39990
Compressor power	kw	2.2	3.0	3.75	4.5	3.0×2	3.75×2	4.5X2	5.5x2
Voltage	3-380V-50HZ
Refrigerant	R22
Condenser	Cooling water m³/hr	2.16	2.8	3.6	4.3	5.7	7.2	8.6	10.8
	Cooling pipe diameter (Inch)	3/4"	3/4"	1	1	1-1/2"	1-1/2”	2"	2"
	Type	Shell and tube condenser
Water pump power	kw	0.37	0.37	0.75	0.75	0.75	1.5	1.5	1.5
Water pump power	Pessure(Mpa)	0.18	0.18	0.18	0.18	0.18	0.18	0.18	0.18
Evaporator	Chilled water m³/hr	1.8	2.4	3.0	3.6	4.8	6.0	7.2	9.0
	Frozen water pipe diameter (Inch)	3/4"	3/4"	1"	1"	1-1/2"	1-1/2"	2"	2”
	Type	Coil /Shell and tube evaporator
Dimension	Length mm	900	900	900	1000	1240	1240	1240	1400
	Width mm	560	560	560	560	670	670	670	750
	Height mm	900	900	900	900	1400	1500	1500	1500


	Model of Machine	20HP	25HP	30HP	36HP	40HP	45HP	50HP	60HP
Cooling capacity	kw	62	77.5	93	111.6	124	139.5	155	186
Cooling capacity	Kcal/hr	55320	66650	79980	95976	106640	119970	133300	159960
Compressor power	kw	7.5*2	9.0*2	7.5*3	9.0*3	7.5*4	7.52+9.02	9.0*4	9.0*5
Voltage	3-380V-50HZ
Refrigerant	R22
Condenser	Cooling water m³/hr	13.8	16.2	18.9	22.6	25.2	28.3	31.5	37.8
	Cooling pipe diameter (Inch)	2"	2-1/2"	2-1/2"	2-1/2"	2-1/2"	3"	3"	3"
	Type	Shell and tube condenser
Water pump power	kw	2.2	2.2	3.0	3.0	3.75	3.75	3.75	3.75
Water pump power	Pessure(Mpa)	0.18	0.18	0.18	0.18	0.18	0.18	0.18	0.18
Evaporator	Chilled water m³/hr	11.5	13.5	16.5	19.5	22	25	27.5	33
	Frozen water pipe diameter (Inch)	2"	2-1/2"	2-1/2"	2-1/2"	2-1/2"	3"	3"	3"
	Type	Shell and tube evaporator
Dimension	Length mm	1500	1600	1820	1900	2000	2100	2200	2300
	Width mm	630	630	650	650	700	700	720	750
	Height mm	1500	1500	1650	1650	1700	1700	1700	1700
Remark: 1.The above data is the standard parameter configuration of our products. If the accessories brand and parameter configuration to special requirements, our factory can custom. 2.The cooling capacity is based on the ice water inlet temperature of 12℃, exit temperature of 7℃; The inlet temperature of cooling water is 30℃, and the outlet temperature is 35℃.

Company Information

Kub OEM Industrial Water Chiller with 3HP to 50HP Semi Hermetic Compressor and 380V 50Hz Power Supply with 1 Year Warranty

FAQ

Q1: Are you a manufacturer or trading company?

A1:This compressor we are agent , But we are factories that produce condensing units, chillers,Evaporator.

Q2: What about the shipping methods?

A2: By express/By air/By sea.

Q3: What about the payment methods &payment terms

A3: We accept T/T ,Paypal, Western Union, Cash and etc.After 30% deposit,and 70%balance before the shipment.

Q4: What's your delivery time?Where is the loading port?

A4: Usually within 35-60 days after receiving the payment. Loading port:Shanghai,other place in china according your requirement.

Q5:Can I have a sample first ?

A5:You have to pay sample cost.

Q6: How do you ship the goods and how long does it take arrive?

A6: We usually ship goods by LCL or FCL by sea, by air or express delivery. Usually it takes 30 days by sea, 5-7 days by air or express delivery.

The delivery time is according to the way of shipping.

Packaging & Shipping

A. Individuation & Customization

Refrigeration industry, cold storage engineering;

Agriculture,food, restaurant, chemical industry; we can undertake designs according to customer's requirements.

B. Excellent warranty

KUB provides up to one year warranty period.

If there is any product quality problems, we will return processing, and is responsible in the end.

We provide excellent service to solve your worries.
